LEARN MORE About the Emerging EMF Public Health Issue from Scientists, Physicians and Other Experts at www.ElectromagneticHealth.org
This site is for people who want to learn how to assess home and office environments for electromagnetic fields, and how to remediate electromagnetic safety problems if they exist. Our philosophy is that one should first learn how to clean up one’s personal environment, and especially one’s sleeping and office environments where one spends long hours. To that end, we offer you a selection of high value-added and economical measurement and safety resources screened and described by expert EMF consultant, Stan Hartman of Radsafe in Boulder, CO.
For more information about electromagnetic factors in health please read the Book, Public Health SOS: The Shadow Side of the Wireless Revolution, available at www.ElectromagneticHealth.org. There you will also find much valuable educational content on this emerging public health issue. Learn—and come back often!
1) Meters. You’ll find a range of meters and detectors here for electric, magnetic and radiofrequency fields, so you can start becoming an EMF detective. It is only when you measure the fields that you can know what fields are present, and how, and from what direction, to remediate with assurance. See Meters.
2) Bed Canopies. Create a bedroom sleep sanctuary so you rest undisturbed by electromagnetic fields and wake up more refreshed in the morning. People who are electrically sensitive find shielding bed canopies essential, as do high performance athletes and, increasingly, business executives bathed in frequencies all day. See Bed Canopies.
3) Shielding Fabrics. Shielding fabric by the foot can be used to line curtains, walls and can even be put under carpets or desk chair pads to shield from the Wi-Fi of neighbors downstairs. See Shielding Fabric.
4) Shielding Films. Placing plastic shielding film on glass windows can significantly block out ambient radiofrequency radiation-from where it comes into the building most easily. See Shielding Films.
5) Shielding Paints and Covers. Metallic water-based paint can be placed under latex paints or wallpapers. Suitable for many types of exterior surfaces as well. Caution: Needs grounding and should not be installed without the services of an electrician. Also, do not put shielding paint on the walls if the room will contain RF emitting devices, such as computers, cell phones, wi-fi, compact fluorescent bulbs, etc. See Shielding Paints and Covers.
6) “Dirty Electricity” Meter and Filters. Increasingly, high frequency transients get on wall wiring and create unhealthy fields. This is especially so in downtown urban environments or where one is operating electronic equipment of various kinds. To see if you have “dirty electricity”, purchase a Dirty Power Meter, then neutralize transients by putting at least one Graham-Stetzer filter in one of the wall sockets on each circuit. See Dirty Electricity Filters and Meter.
7 ) Reducing Cell Phone Headsets, Cell Phone Cases This is the best headset-the one where the sound travels up the plastic air tube limiting the amount of radiation to your brain from either cell phones or portable phones. If you must use a cell phone, using this headset will reduce radiation to the brain significantly. Hands Free RF Reducing Headset. See RF-Reducing Cell Phone Headsets.
8 ) Cell Phone Warning Signage. See Cell Phone Warning Signage.
9 ) Books and Other Resources. See Books and Other Resources.
10) Grounding Devices. See Grounding Devices.
11) Computer Accessories. See Computer Accessories.
12) Smart Meters. See Smart Meters.
Return Policy: 14 days to return unopened items in new condition for refund of purchase price less shipping and handling and 20% restocking fee. No returns on paints or on custom goods such as cut fabrics and films. To return items contact Info@ElectromagneticHealth.org for authorization and shipping instructions.
To obtain the E-Book, Public Health SOS: The Shadow Side of the Wireless Revolution, which goes into depth on safety and remediation concerns for consumers click here.
For questions please email Info@ElectromagneticHealth.org.
3-Axis RF Meter
Very Sensitive, Affordable, Feature-Packed RF/MW Meter
Covering a bandwidth of 50 MHz to 3.5 GHz, digital and analog, this instrument is incredibly versatile. It’s 3-axis, which means you won’t miss brief pulses that could disappear before you turn the meter to check another direction, but you can also select one axis at a time to help locate the source of the radiation. With 2½ samples/second it’s also fast, which is very important when tracking microwaves. But there’s more. It has a selectable audio alarm with adjustable sensitivity, selectable auto-off, and backlighting that automatically turns off after 30 seconds. Its 4-digit LCD display reads in either mV/m, A/m, W/cm², or W/m². The display also includes an analog bar graph, and is switch-selectable between instantaneous value, maximum value, or average value. But there’s more still – it also has a 200 point manual memory function, and is extremely sensitive. On the millivolt per meter scale its sensitivity is: 38 mV/m to 11 V/m (equivalent to .38 nanoWatt/cm² to 30 microWatt/cm²). It’s accuracy, incidentally, is a respectable ± 2.4 dB or better. Power is from a standard 9V battery, giving about 15 hours of continuous use. Comes with a 1-year warranty.
3-Axis RF Meter(Cat. #WAH495) …………… $199.95
8 GHZ RF METER
Very Wide Frequency Range
Extremely wide frequency rage radiofrequency (RF) meter—from 10MHz to 8 GHz. An exceptional value for the price in terms of the range of frequencies covered. Will pick up the new 5.8 GHz phones as well as other RF equipment such as DECT portable phones, wireless routers, baby monitors, etc. Will also measure some radar exposures that sweep through certain communities. 3-axis (isotropic) measurement. Extremely sensitive: 20 mV/m to 108 mV/m (or, 0.1 nanoWatt/cm2 to 3 milliWatt/cm2). Measures exposures in V/m, A/m, W/m² or W/cm². Displays instant value, max value or average value, where the average value interval is adjustable from 4 seconds to 15 minutes. Excellent ±1dB accuracy or better. One year factory warranty. (Uses 9V battery)
ESI 24 EMF MONITOR
Detects & Displays All 3 EMF Types at Once
The ESI 24 checks for all 3 types of EMF: magnetic fields, electric fields, and radiowaves/microwaves at the same time. Easy to read display indicates field strength with either a red, yellow, or green led lights, along with an audio confirmation of the field strength. The audio function is optional. The display shows 5 levels, ranging from extremely low to too strong for prolonged exposure and distinguishes how much for each radiation type. Very user friendly and very sensitive.
The ESI 24 has an Enhanced RF, allowing the user to measure only RF using all 15 LEDs, giving greater range and resolution. Sources detected by ESI 24: cell phone towers, cordless phones, wireless LAN, Wi-Fi systems, power lines, electrical installations and appliances, baby monitors and alarms, microwave ovens, cell phones, etc.
Operates for about 10 hours on one 9V battery (included). 2 year warranty.
DIGITAL COMBINATION METER (Magnetic & Electric Fields)
Accurate Single-Axis Gaussmeter and AC Electric Field Meter
This German meter, by GigaHertz Solutions, offers 2% accuracy (±20 digits) at 50/60 Hz, with a very flat frequency response, within 1 dB from about 16 Hz to 2,000 Hz (printed as a graph on the cover of the case). It’s overall sensitivity is much wider, though, from about 5 Hz to 7,000 Hz (at 3 dB accuracy). Its very low frequency cutoff makes it versatile but slow (on the magnetic setting), because whenever you move it you have to wait a couple seconds for it to settle down and give you an accurate reading. Remember that with a single-axis meter you really need to take three readings 90º from each other (find the orientation with the highest reading and visualize the meter flat against one surface of the corner of a box, then take readings flat against each of the other two sides) to get the true flux density. If two of the readings are much lower than the highest one, you can usually get away with just increasing the highest reading a bit and calling it right, but if one or more of the lower readings is close to the highest one, you need to do the calculation – square each reading, add them together, and take the square root of the sum.
Its magnetic resolution is extremely fine at 10 microgauss, but its top end at 20 mG will leave you wondering at an out-of-range indicator in areas with stronger fields. Another slow-down for those used to readings in milligauss is that this meter reads in nanotesla. That can be remedied by putting a decimal point on the display with a felt-tip pen between the second and third numerals from the right – as long as you remember to ignore it when reading electric fields.
The electric field setting ranges from 1 to 2,000 volts per meter, and actually uses the operator’s body in its detection, making it unique but a bit awkward. You have to plug a ground wire (generously long, at least) into the meter, with the other end grounded somewhere, and always keep the wire behind you while you hold the meter close to your body, making it necessary to get up close and personal with whatever you’re measuring. This does away with the need for a long handle so your body doesn’t interfere with the field, but since no one’s bodily electric field is exactly the same, how accurate can it be on the electric field setting? It is an accurate gaussmeter, however.
As with many of this company’s instruments, it’s well-made but design flaws limit its usefulness in the field. Their more expensive combination meter is actually less useful than this one because it’s bandwidth is too broad for ELF testing, which is what most AC gaussmeters are designed and used for. The audio output of this meter, incidentally, is not really sensitive enough to be very useful. The much cheaper Gauss Master, and Budget Buzz Stick (see below), are much better at audio indication of magnetic fields.
All in all, for the price, this is a very useful and accurate, if slow, gaussmeter, and also actually measures electric fields, if you don’t mind the inconveniences. It operates on a standard 9 volt battery, and comes with an excellent, very informative manual and a 2 year warranty.
SWITCHABLE SINGLE AXIS AND 3-AXIS GAUSSMETER
This user-friendly digital gauss meter measures ELF (13 Hz to 1 kHz) and VLF (1 to 75 kHz) magnetic fields. Range from 0.01 mG to 1999 mG. It has a 3% accuracy from 45 to 5000 Hz but is still useful from 13 Hz to 75 kHz.
The meter can be switched between single axis and 3-axis mode. For fast and reliable routine measurements, use the 3-axis mode. To identify the specific orientation of the field, put the meter in single axis mode. See instructional video below. Made in USA. One year manufacturer’s
Versatile and Great Value
This reasonably priced meter features a large backlit display that simultaneously displays both electric field and magnetic field readings. Can be used to check for emissions from powerlines, household wiring, appliances, and anywhere that electricity is flowing. In addition to the field strength number, the meter includes a visual and sound indication (alarm) when the field detected exceeds the pre-set “danger” threshold of 40V/m or 0.4\f1µ (4 mG)–very handy when measuring large areas or monitoring emissions over long periods.
- Additional features:
- Single Axis
- Simultaneous readout of electric field in V/m and magnetic field in µ
- Range 1-1999 V/m, 0.01-19.99 µ (=1-1999mG)
- Preset audio alarms: 40V/m or 0.4µ (=4 mG)
- HOLD feature locks display for easier reading
- Switchable Average vs. Peak modes
- No accuracy specification
- Covers ELF and VLF frequencies
- Very simple to operate
- Display and instructions in English
- Requires one 9V battery
MicroTesla Meter (Cat. #WA114) …………… $49.95
BUDGET BUZZ STICK (Magnetic Fields)
The Intimate Sounds of ELF Magnetic Fields
This little unit won’t actually measure anything numerically, but is a great sniffer-outer of magnetic fields, letting you listen in to their hums, buzzes, clicks and squeals. It will even give you a relative indication of their field strength – louder means stronger. And because it doesn’t have to measure anything, it’s very fast, giving you a real-time indication of your ELF magnetic environment. It will show you magnetic phenomena that a gaussmeter is incapable of detecting, like very low 1 Hz clicks from a digital clock, computer clock, or thermostat, pulses from a cell phone battery, and very strange noises from some GFCI outlets that may make you wonder if there’s a listening device in your kitchen. The pitch of the sounds can even be like an audio frequency counter, giving you an indication of what frequency spikes and harmonics are present. The little pickup coil on a 2-foot cable can also find fields in hard-to-reach spots you could never get a gaussmeter into, much less read it. There’s a mono earphone jack that cuts off the speaker if you want to listen privately or don’t want to scare the cat.
And if grandma has trouble hearing phone conversations, you can always attach the little coil’s suction cup to the back of your phone, turn up the Buzz Stick’s volume, and everyone can listen in. It uses a standard 9 volt battery.
ULTRA SENSITIVE WIDEBAND RF METER
This is a very sensitive meter, designed to detect everything from 1-2500 MHz and can differentiate between distant sources like cell towers and nearby sources like cell phones. The meter has an analog readout on a relative scale to make direction finding fast and easy. Comes with instructions and 9V battery. Made in America.
GAUSS MASTER™ (Magnetic Fields)
The Little Meter That Can
This meter has actually been around a long time. It was originally called “Dr. Gauss,” and is probably the cheapest actually useable gaussmeter available (there are cheaper ones, but the key word is “useable”). Don’t depend on it for accuracy, though the analog meter is calibrated in milligauss, but it will definitely show you where magnetic fields are and give you a ballpark sense of their strength. It has a selectable super-sensitive setting (1 mG full scale); the normal scale is 1-10 mG. It also has a very useable audio output, which can impress children more than a meter needle when they hear it squeal insanely close to the microwave oven or the electric range.
Some annoying things about it are that it has no power LED (it actually does have one, but it’s inside the case, and you’d have to drill a hole right above it to see it), or anything else to tell you that it’s on if you’re in a low-field environment. That wouldn’t be much of a problem except that it shuts itself off automatically after five minutes, so you can sometimes think the fields are very low when the meter has just said goodnight. You can get around that, though, by just pressing the ON button more than once every 5 minutes (holding it down is what selects the more sensitive range). Another annoyance is that the audio output can’t be turned off.
The Gauss Master can also be affected by higher frequency radiation (cell phones and other RF), but this can be remedied if you suspect it by finding the highest reading and then shielding the meter with your body – holding it close and turning around in a circle (always keeping the meter oriented in the same absolute direction). If the readings don’t change significantly, you can usually assume that RF is not a problem. Remember, as with any single-axis meter, to take three readings 90º from each other (see the DIGITAL COMBINATION METER above).
It uses a standard 9 volt battery, and comes with useful instructions on how to conduct a magnetic field survey.
The Acoustimeter shows average, peak and peak hold levels of radio frequency electromagnetic fields. It covers the spectrum from TETRA up through and beyond the 5.6 GHz WiFi and WiMax frequencies. It is user-friendly and accurate. It has a digital readout with LED light and LED text, which is sensitive 0.02 V/m – 6.00 V/m and a sound output enabling you to hear the signal. These instrument is useful to even those with severe electrosensitivity.
The Acoustimeter is a broadband instrument that measures the radiation in the range 200 MHz to about 8000 MHz (8 GHz), which covers the frequencies used by most modern communication systems encountered in our daily life. The Acoustimeter was designed using the experience from many years of practical RF and microwave measurements.
The readings are shown on both an LCD display and two series of graduated LED lights. The LEDs update rapidly, and allow you to quickly gauge the levels in an area and find hot-spots.
Comes with a 2 year manufacturer’s warranty.
The internal antenna is at the top rear of the case. It is best to measure signals with the source behind the instrument or to one or other side (particularly the left side away from the switches and volume control). It under-reads if the source is in front of the meter as the LCD display acts as an RF screen.
This is a reliable meter for an excellent price. Use for checking sources of radiofrequency fields, such as smart meters, Wi-Fi, cell towers, cellphones and other wireless devices. Field strength is measured in V/m and is indicated on an 8 LED light display, so it is very easy to understand. Includes an optional sound feature that allows you to hear the intensity of the field and an alarm to indicate higher exposure levels. The Acousticom2 covers a range of 200 – 8000 MHz with ±6dB accuracy. A 9V battery is included.
• Range (Peak Display): 0.01 – 6.00 volts per meter (V/m)
• 0.01 V/m increments; (0.5 to 100,000 µW/m²)
• Power draw: 40 to 90 mA
• Battery life: Up to 10 hours
• Size: L 110mm x W 63mm x D 21mm; Weight: 140g with battery
Note: Fields are best measured when the instrument is behind the source, as the internal antenna is at the upper back of the meter’s case.
Acousticom2 (Cat. #WAH140) …. $249.95
This highly sensitivity Geiger counter detects alpha, beta, gamma and X-rays. The meter is very simple and user-friendly in basic mode, but comes with advanced features such as the ability to adjust averaging time and switch between mR/hr to mSv/hr. The data can be transferred to and analyzed on a computer or a datalogger (USB cable and Pc software included). Can operate in mR/hr, CPM, or total counts. Easy to read 4-digit LCD display and audible tone.
Runs with a 9V battery. Comes with padded vinyl case and one year warranty
Detector: halogen-quenched uncompensated GM tube
Window: thin mica (1.4-2.0 mg/cm²); effective diameter 45mm
Averaging: display updates every 3 seconds; averages every 30 seconds or less
CPM: 0 – 300,000
Total Counts: 1 – 9,999,000
mR/hr: 0.001 – 100
microSv/hr: 0.01 – 1000
CPS: 0 – 5000
mR/hr: ±15% from 0-50 and ±20% from 50-100
CPM: ±15% from 0-130,000 and ±20% from 130,000-300,000
Outputs: Dual miniature jack drives CMOS or TTL devices
Temperature: -10°C to +50°C
Size: 150 x 80 x 30 mm
Weight: 301 g (excluding 9V battery)
MONITOR 4: RADIATION MONITOR
This Geiger counter detects Alpha, Beta, Gamma, and X-rays with an easy to read red light count and audible indicator. The meter detects alpha rays down to 2.5 MeV, 80+% efficiency at 3.6 MeV. Beta rays are detected at 50 keV with 35% efficiency, and 150 keV with 75% efficiency. Gamma and X-ray are detected down to 10 keV. Meter has a range of 0.02 – 50 mR/hr. The analog meter features a quenched uncompensated Geiger Mueller tube with a thin mica window.
Uses 9V battery. Comes with a one year warranty.
An inexpensive meter with great portability and data logging capabilities.
This pocket sized Geiger counter detects Beta and Gamma (0.1~1 MeV) and is sensitive enough to measure background levels. It will log data with a time stamp every second, minute, or hour and can be connected to a PC ( Windows XP, Vista and 7) through a USB port to download, analyze and manipulate your data. It’s range goes up to 65,535 CPM (200 microSv/hr or 20 mR/hr). The readout is in count per minute (CPM) or exposure rate microSievert/hr (µSv/hr) or (mR/hr). The meter has an audible alarm with an adjustable threshold.
This pocket sized Geiger counter measures 5”x3”x1” and comes with a rechargeable 9V battery, although an alkaline 9V battery, AC power adapter (or vehicle adapter) can be used as well. For use indoors or outdoors. Meter can be wall mounted.
2) Bed Canopies.
SHIELDING BED CANOPY
For RF-Quiet Rest
This washable microwave shielding keeps its conductors on the inside of the fabric threads so there’s no metal flaking and, while letting in air and light freely, reduces exposure to 300 MHz to 3 GHz radiation by more than 20 dB (that’s 99%). There’s enough material to shield above and around the sides of the bed, with plenty of head room. It’s made of Swiss Shield Daylite fabric, which is 100% Tergal® polyester net-knit, over the 5% silver-plated copper conductors. It’s mounting is made easy with swag hooks and a detachable hoop. Feedback from owners reports significant reduction in electrosensitivity symptoms.
Comes in 2 sizes:
3) Shielding Fabrics.
HIGH PERFORMANCE SILVER MESH FABRIC
“60dB in a Mesh Your Can See Through”
This high performance silver mesh fabric offers maximum shielding performance. Surface resistivity is <0.5 Ohm/sq. Shielding effectiveness is >60dB from 30 MHz to 3 GHz! Can be used over a wide range of temperatures (-30° to 90°C) to shield electronic components, make draperies, tents, mobile phone shields, and more. Used in medical applications also. Good tear strength and attractive Silver color. Very soft and comfortable to touch. 0.0045 inch thick, weighs only 40 grams/m². 58″ wide.
2-Way Stretch Shielding Fabric
Silver coating is 99.9% pure. Width: 135 cm wide (approx. 52 inches) but note it varies from lot to lot. Weight: 4.3 oz/yd² . Thickness: 0.40 mm. Stretch: ~100% in length direction; ~65% in width direction. Surface resistivity is < 0.5 Ohm/sq. (unstretched) . Temperature range: -30 to 90°C
Stretch Conductive Fabric (Cat. #WAH321) …………… $31.95 per lin ft
Swiss Shield Fabrics
Swiss Shield fabrics are lightweight RF shielding fabrics that are highly effective as well as attractive. They shield from cellphones and cell tower radiation, cordless phones, wi-fi, radar, microwave oven leakage, TV broadcast, etc. Certified to contain no harmful substances by OKEO-TEX 100 (Class 1). They contain no flame retardants.
EVOLUTION ULTRA™ FABRIC
Lightweight, conductive shielding fabric from SwissShield
This fabric is high-quality, translucent, lightweight, semi-transparent and has all textile characteristics. It is a polyester fabric mesh with pure silver coated copper threads woven throughout. This fabric both provides a conductive surface (5 Ohm/square) and is laboratory certified to shield RF. The fabric allows air flow, is machine washable (use TexCare) and can be cut and sewn like ordinary fabric. Light gray color.
76 g/m2 8.2 feet wide.
Polyester, 6 % copper / silver
Polyester fiber with a gossamer-thin 0.02 mm silvered and PU-coated spun-in
250 cm wide
Oeko Test 100 Class 1 (baby underwear)
STR, Swiss Textile Research Institute,
MAXWAVE Zurich according to MIL-STD 285 and IEEE Standard 299-1997
Swiss Shield NATURELL™
Naturell™ is often used for bed canopies, curtain linings or drapes. It is a very attractive, ecological, unbleached ecru-white cotton fabric with zero chemicals, preferred by the natural and health conscious consumer. It provides the greatest shielding of the Swiss Shield fabrics (38 dB at 1 GHz). Comprised of 82% cotton, 17% copper, 1% silver. Extra wide (8.2 feet). Machine washable, gentle cycle. Hang dry. Iron with no steam, low heat. Do not use bleach or dry clean. Weight: 69 g/m2.
Swiss Shield “WEAR”
This is a thicker more durable cotton then Naturell. Can be dyed any color. Easy to cut, sew and iron. Contains: 90% cotton, 9.5% copper, 0.5% silver. Attenuation: 29 dB at 900 MHz. Often used for bedding or mobile phone cases. Some use for clothing though we do not advise this as this, as many experts urge caution about using shielding fabrics on the body. With up to 30 washings shows little loss of performance. Width: 59”. Weight: 115 g/m2. Good value.
Swiss Shield DAYLITE™
This is a highly transparent white polyester mesh fabric that is light weight. It gets good light penetration as well as air circulation, so it is especially appropriate for bed canopies and curtains, though depending on how much RF there is sometimes people prefer double layers. Attenuation: 20 dB at 1 GHz. Some use Daylite™ for head coverings, but we do not advise this, as many experts urge caution about using shielding fabrics on the body. 92% polyester, 7.5% copper, 0.5% silver. Extra wide (8.2 feet). Machine washable, gentle cycle. Hang dry. Iron with no steam, low heat. Do not use bleach or dry clean. Weight: 65 g/m2
This is a very soft, light grey cotton knit fabric woven with silver that is comfortable and washable. 90% cotton, 10% Silver. ~99% RF attenuation from 800 MHz to 18 GHz. 62 inches wide. Soft and stretchy.
4) Shielding Films.
SCOTCHTINT™ SHIELDING WINDOW FILM
Windows are the most important areas of a room to shield, because they’re the principal portals for RF/MW radiation. This window film will reduce exposure to radiation in the 30 MHz to 4.5 GHz range (the frequency limits of the testing) – by more than 22 dB at cell phone frequencies. You simply cut it to size, peel the backing, wet it, and apply, then squeeze out any air pockets. It’s good to cut it a little large so you can then use an exacto knife to trim it as close to the frame as possible, especially along the vertical edges.
In addition to RF shielding, this film reduces heat gain in the summer by up to 79%, and heat loss in the winter, and makes windows opaque from the outside when the sun is on them, without reducing visibility from the inside. This can mean saving about one ton of air conditioning for every 100 sq. ft. of sun-exposed glass, and a reduction of up to 30% of heat loss in the winter. It also reduces glare and blocks 98% of UV rays, protecting interior surfaces from fading.
You can find professional installers in most areas if you don’t want to do it yourself. For Installation Instructions Click Here.
Scotch Tint is Available only in 100 ft rolls and silver-blue tint, in two widths.
|ScotchTint Shielding Performance|
|30 MHz||24 dB||1 GHz||24 dB|
|100 MHz||22 dB||2.5 GHz||26 dB|
|300 MHz||22 dB||4.5 GHz||27 dB|
|Shading Coefficient .26||Emissivity .65||Glare Reduction 78%|
|Visible Light Reflected 58%||Heat Gain Reduction 72%||”U” Value .95|
|Visible Light Transmitted 19%||Heat Loss Reduction 10%||Visible Light Energy Rejected 77%|
ScotchTintTM 36″ wide x100′ (Cat. #WAH1215-36) …………… $599.00 per roll
Trial size: 36″ wide x 25′ (Cat. #WAH1215-36-25) …………… $270.00 per roll
Microwave Absorbing Carbon Laminate
Non-woven carbon fiber offers shielding as well as high microwave absorption. Appealing as a shielding option when you’d rather not use only reflecting shielding (to protect people in the vicinity whom the waves might be reflecting towards). The carbon material has a plastic laminate on it for ease of handling, reduced carbon dust and durability.
Carbon base material (without plastic laminate): Width: 48 inch (1219 mm), Weight: 34 g/m², Thickness: 18 mil (0.445 mm), Resistivity: ~3 Ohms per square, Tensile: 47 N/15mm. Relatively hard, inflexible material compared to fabrics though very light weight. Air and light do not penetrate. Use to line walls or for partitions or to line heavy curtains.
Please note, with some lighter weight shielding fabrics, which may not shield 100%, sometimes just using carbon laminate underneath the fabric to absorb stray microwaves can do the job. It is always best to purchase an Electrosmog Meter. to assess the RF/MV remediation results. Sometimes more than one layer of the carbon laminate is needed to reduce the microwaves to zero, but note with the carbon laminate this can be accomplished at a much lower cost than using multiple layers of the shielding fabrics.
Also helpful to absorb stray microwaves on rooftops where an antenna has been placed. Place this absorber underneath a metal shield.
5) Shielding Paints and Covers.
Y-SHIELD Indoor/Outdoor Paint
High Frequency Shielding Paint
This is a water-based paint for shielding interior or exterior surfaces from radio frequency and microwave radiation up to 18 GHz (see graph below), reducing RF/MW by 99.99% (40 dB) with one layer. With a pure acrylic binder, it adheres well to masonry, cement, plaster, construction board, polystyrene, latex paint, and many other surfaces, is frost-resistant, dries quickly, cleans up with water, and comes ready to use.
The surface of this paint is highly conductive (about 10 ohms per square), and attenuation is consistent no matter what the polarization of the signals because of its holohedral carbon structure, without fibers or meshes. About 10% of the shielding is accomplished through the carbon’s good RF dissipation, which reduces reflections from both outside and inside the area to be shielded. It does need to be grounded.
It’s RoHS compliant, comes in black only, covers 50 to 100 square feet (5 to 10 square meters) per liter, and can be covered with latex paint, wallpaper, etc. It has a shelf life (unopened) of 15 months.
The minimum temperature for applying it is 1°C (33.8°F), and it can be shipped in the winter or any other season. It weighs 3.2 pounds per liter.
Fiber Additive for Y-Shield Paint
Prevents Loss of Conductivity
Y-Shield paint can lose some conductivity due to cracking after drying when it has been applied to an uneven, porous, expanding or exterior surface. This additive contains long, electrically conductive carbon fibers which create a conductive path across any cracks that might form. Instructions: Using an electro mixer for at least 1 minutes, stir in 90 ml (3 oz) of additive to 5 liters (1.3 gallons) of shielding paint.
Circuit Breaker Shield
Decorative Magnetic Shielding
Strong magnetic field emissions (depending on how much electric current is flowing) and electric field emissions from a circuit breaker box (or fuse box) in any living space can be hazardous. Shielding must not hamper quick and easy access to the controls inside the box.
Make your own hinged shield from materials below if you know how. Otherwise, for a simple solution use this method: Hang a framed picture that has high-performance Giron shielding material adhered to the back of it over the circuit breaker box. The larger the shielded area, the more protection. Tests have found a 50-70% reduction of magnetic field from a 2-foot section of Giron in a 24×36 inch frame.
Three Easy Steps:
- Purchase Giron, 25.5 inch wide x 24 inch
GIRON for Poster (Cat. #WAH273-24P) …………… $89.80
- Get either a framed picture, mirror, Dry Erase board, or a cork bulletin board with a wood frame (samples only, use what you prefer), at least 24×36 inches
- Insert cardboard behind the framed object. Carefully, insert Giron behind the cardboard (the edges are sharp). Adhere Giron with duct tape to hold in position, if needed. Center Giron over the magnetic “hotspot” on the wall, and hang your picture. If there’s room, insert another layer of cardboard behind the Giron. Final product weighs about 9 pounds, depending on the frame selected.
6) “Dirty Electricity” Meter and Filters.
DIRTY POWER METER
Low Frequency Noise Detector
Not for testing Washington politicians, this meter lets you detect levels of dirty power in home or office wiring, which can be corrected by installing Graham-Stetzer Filters (see below). The filters mitigate low frequency noise between 4 and 100 kilohertz, and this meter is designed to measure microsurges – voltage spikes – in that frequency range and display them as a numerical equivalent, in volts per second, of such noise.
No batteries are required – just plug it into a standard 2-or-3 prong or GFCI outlet and read the display. It works for 60 Hz, 120 Volt North American and 50 Hz, 240 Volt European systems (but an ordinary plug adapter is needed for European or other electrical outlets). By turning on various appliances (compact fluorescent bulbs, blenders, computers, laser printers, etc.) one at a time and taking readings, you can get a sense of which are the biggest polluters. The rule of thumb is that any outlet reading higher than 50 should get a filter – especially if it’s in an area frequently occupied (bedroom, office, etc.).
High Frequency Pollution Meter for Wiring:
GRAHAM-STETZER FILTERS—ELECTROMAGNETIC POLLUTION REMOVERS
Dirty Power Cleaner
Wherever there are active dimmer switches, electric motors, fluorescent lights (including CFLs), transformers, and many other electric-noise producing products, you also find dirty power in the form of microsurges – spikes of higher-frequency on the normally extremely low frequency (ELF) power in our homes and offices. This higher-frequency noise has been associated with symptoms of electrosensitivity (skin rashes, insomnia, depression, headaches, inability to concentrate, memory problems, fatigue, etc.), and possibly even more serious diseases like cancer. These small filters, when inserted into wall outlets, reduce this higher frequency noise, resulting in relief for many people.
They use no extra electricity but simply act to clean the electricity moving through the electrical system, which can make other electrical appliances run more efficiently and may actually reduce your utility bills. Each can easily be moved from one outlet to another as needed (for a detector of dirty power, see the DIRTY POWER METER above).
Though they can be ordered one at a time, the normal package of 20 units will clean the power of an entire, average-size home or office.
North American plug style:
7) Reducing Cell Phone Headsets, Cell Phone Cases.
AIR TUBE HEADSETS
“Minimizes Radiation Around the Head”
AIR TUBE headsets are designed to minimize your exposure even more because there are no speakers or electronics (no EMF) in the earpiece itself. The sound is carried through a tube into your earpiece, so that radiation and EMF can’t travel through the wire into your ear.
Ear-bud style with soft rubber cushions. The cord is 39 in. and has a built-in microphone. Works with most phone models. Patented. Please check your phone for which plug style you need.
Air Tube Headsets:
For iPhone and similar models:
For most cordless phones and other styles:
2.5 mm, 3 band plug (white) Mono – one ear bud (Cat. #WAH281) ……….. $19.95 Buy Now
This soft, protective phone case has two compartments. One compartment completely encases the phone in shielding fabric, reducing your radiation exposure by as much as 96%. The other compartment has shielding fabric on only one side, allowing the phone to make and receive phone calls, while helping to shield your body on one side while you carry it or while talking on the phone. Note: while the phone is shielded on one side, your radiation exposure is not eliminated, just reduced. Please use with moderation! Color is black.
Regular Size: (3” x 5½”) fits most phones
Large Size: (3½” x 6½”) fits most phones
Shielded Your Favorite Phone Case
BlocSockLite is a thin insert that lines the inside of a standard phone case. It can be trimmed to fit as needed and peels and sticks to hold in place. BlocSockLite has a layer of metalized fabric that offers 65 dB or better shielding, but the face of the insert is soft fabric so it won’t scratch the screen of the phone.
Like the original BlocSock, the BlocSockLite allows the phone to receive and make phone calls while shielding your body from some of the radiation on one side. Please make sure that the side facing your body or head is the shielded side!
5-5/8” x 2-7/8” (143×72 mm) with rounded corners.
Laboratory Tested to Reflect up to 99% of Microwave Radiation Away from the Body
When carrying a cell phone in your pocket, your vital and reproductive organs and all systems of your body are being exposed to microwave radiation, which dissipates internal. The Pocket Sticker is designed to protect your body from 99% of the radiation being emitted by your cell phone while carrying it. Made of high performance shielding material, Pocket Sticker is a peel-on patch that reflects radiation away from your body. Easy to apply. Invert pocket, cut patch to size as needed (the bigger area the better) and stick on. Use patch on jackets or other loose fitting clothes—not on skin-tight clothing. Just make sure that it is placed between the phone and your body—NOT on the outward side of the pocket as that would reflect the fields back towards you.
- Pocket Sticker fabric: 90% cotton, 9.5% copper and 0.5% silver
- Dimensions: 16cm x 10cm (6.25″ x 3.9″)
- Care Instructions: Machine wash, cold water. No bleach. Do not dry clean.
Each package contains 3 patches.
MOBILE PHONE POD
“Dual-Pouch Shielded Bag”
The Mobile Phone Pod is dual-pouch shielded bag. Like the BlocSock, it has two compartments. One is completely shielded, keeping the phone form making or receiving phone calls and nearly eliminating the radiation you are exposed to. The other compartment is shielded on just one side, allowing the phone to receive and make phone calls, but reducing the radiation you are exposed to on the shielded side. Please make sure that the side facing your body or head is the shielded side!
Measuring 4”x6” the Mobile Phone Pod easily fits most phones and iPods (including the Otterbox™). Durable black or white leather-like finish.
Mobile Phone Pod:
SHIELDED CELLPHONE HOLSTER
Shielded Leather Holster with Belt Clip
Keeping your phone in your pocket or on your belt exposes the abdomen and reproductive organs to radiation. This holster with belt clip is shielded on the back, allowing the phone to receive calls, while reducing the amount of radiation you are exposed to.
Genuine leather with a magnetic flap that opens at the top and seals securely. Swivel belt clip can hold the unit vertically or horizontally. Fits Blackberry 8300, Motorola Razr, and similar phones up to 4.5’x2.6×0.6’.
Stereo Hands Free Headset with Microphone
Keep your cell phone farther from your head and body with this stereo headset. Headset has a gold plated 3.5mm, 3 band plug. Sporty lightweight design, this headset provides clear stereo sound quality comfortably to your ears. The convenient microphone allows you to make and receive calls at the touch of a button. Compatible with all universal 3.5mm headphone jacks. Can be used with Ferrite Snap Bead to further reduce RF exposure.
CUP HOLDER MOUNT FOR PHONES & GPS
Keep Radiation Away From Your Body While Driving
This mount plugs securely into a cup holder and is adjustable to any position, keeping your head and body farther from the radiation and allowing you easy access and hands-free use of your cellphone, GPS or iPod while you drive. Cradle is adjustable and can accommodate devices up 3.5 inches wide.
CRUZ CASE for iPhone
Simply flip the lid of the Cruz Case open to receive and make calls, then close back into protective mode. Talk and listen through the lid with excellent clarity. Fits iPhone 5 (Cruz Case for iPhone 6 currently out of stock).
OVER THE HEAD HEADSET
‘Hands Free’ over-the-head headset for use with cell phones, and also with tape or CD players. This is for people who prefer for comfort the ‘over-the-head’ style to headsets with only an earbud. Significantly reduces cell phone radiation to your head. You can use this with the microphone on either side. Also features an adjustable boom microphone for optimum voice output and a four-foot cord. Comfortable, solid feel that stays in place better than headsets with earbuds and goes on quicker.
Standard 2.5mm 2-band jack for use with office, home, cellular or wireless phones. (black)
Create more distance between your body and the radiation coming from your phone. These headset extension cords are 12 feet long and you can connect up to 2 of them at once for a full 24 feet.
FERRITE SNAP BEAD
An RF-Sponge for Wiring
Headset wires (and anything else metallic) can become an antenna for high-frequency signals and noise, and transmit the RF to your head. A ferrite bead acts like a sponge for high frequencies and keeps them from continuing on to the ends of the wires closer to your body. The two halves of the small bead snap together around the wires and “soak up” the RF. They’re very light, grey in color, and about an inch long, with a minimum of 50 ohms impedence. They fit wires 5 mm in diameter or less (you can knot smaller wires at each end of the bead to keep it in place).
Ultra Low EMF Telephone
This is a fabulous home or office phone for people who are sensitive to the strong magnetic fields associated with the handset, speakerphone or telephone base of many conventional telephones.
Desktop or wall mount corded telephone (no microwaves) combined with a special ultra low EMF headset. The special headset cord is about 3 feet long and uses a clear plastic tube to carry the sound to your ear. No electronics, wires or magnets are near your head. The cord can be extended up to 9 feet with optional extension cord, sold separately. Reduction in magnetic fields is significant.
Features speed dial, redial, speakerphone and a hold button. Phone is white, and has volume control. The phone itself does not have any shielding or EMF reduction technology. Instead the benefit derives from the jack for the special headset. Please note if you already have a phone with a headset jack you only will need to buy the headset alone and not the telephone.
Ultra Low EMF Telephone – White (Cat. #WAH725W) …… $99.95
Need extra length? Connect up to 4 of these extensions between the headset and the phone base. Each extension is 6 feet long.
Already have a phone with a headset jack? You can order just the special headset.
EMP FARADAY BAG
Prevents The Passage Of Electric Charge, Microwaves, And Moisture
EMP Faraday Bags are designed to protect sensitive electronics and other items against EMP current, static discharge, microwave transmission, RFID snooping and moisture damage.
EMP Faraday Bags are recommended to protect:
- Flash drives
- Floppy disks
- Homeopathic remedies
- Credit cards
- And much more!
The Small 8X8W bag is ideal for cell phones, iPods, flash drives, GPS and small cameras. Large 16×18? bag is ideal for laptops, gaming systems, radios and accessories.
EMP Faraday Bags have a 38-pound puncture resistance. The multiple layer construction provides full protection against ESD, EMI/RFI and tribocharging. The moisture barrier performance exceeds foil laminates for low Moisture Vapor Transmission Rate (MVTR), even after flexing. Opening can be heat sealed with a hot iron. Manufacturer recommends double bagging for best results. Does not provide magnetic shielding.
*EMI Shielding (MIL-B-81705-Rev-C): >40 db Between 1 & 10 GHz
*Resistivity-Conductive Metal Layer (ASTM D-257): <2 Ohms/sq.
*Surface Resistivity (both surfaces) (ASTM I-257 @ 12% RH): <10 12 Ohms. sq. in.
*Static Decay (FTMS 101C, Method 4046.1 5000 to 0 Volts): <0.05 Seconds
*Capacitive Probe Test (High Voltage Discharge) – (EIA-std 541/Appendix E-1 KV): <8 Volts
*Charge Generation-nominal (Modified incline plane Avg. nC/sq.in.):Teflon: -0.09 Quartz: +0.10
*Total Thickness: 7.0 mils
*Light Transmission (ASTM D-1003-77) <.01%
*Tensile Strength (ASTM D882-83 Method A) 735 lbs.
*Tear Strength: (D1004-66 – Notched) MD: 5.8 lbs. TD: 7.5 lbs.
*Burst Strength (FTMS 101-C Method 2007 1a) >130 psi
*Puncture Strength (FTMS 101-C Method A) >38 lbs.
*Elongation (ASTM D822-83 Method A)MD: 40% TD: 74%
Meets the military specification MIL-B-81705-Rev-C
EMP Faraday Bag
Small 8×8 inch: (Cat. #WAH264S) ………….. $6.95
Large 16×18 inch: (Cat. #WAH264L) ………$15.95
iPhone RETRO HANDSET (mini version)
Decrease your radiation exposure by 95%, simply by increasing the distance between the phone and your head and body with this stylish black handset. Plugs into iPhone 4, 4S, 5 and most cell phones with a 3.55mm jack. This handset has less echo than some hands free sets, has an answer key and volume control.
iPhone RETRO HANDSET (mini)
(Cat. #WAH348) …………… $19.95
iPHONE EXTENSION CORD
Add length to your headset cord, allowing you to keep the cell phone even farther from your head and body. This extension cord is 3 feet long and works with a standard 3.5mm, 3 band phone jack. One end goes into the phone, the other end connects to your headset. You can combine up to 4 extensions cords, allowing you to get 12 feet away.
Protect Your Private Information
This shielded passport jacket blocks the transmission of the high frequency waves used to read smart (contactless) passports. The jacket protects your passport from identity theft. Passport slips in and out easily to present it to authorities.
Dimensions: 3-3/4 x 5-1/8 inches, fits most passports.
Passport Shield (Cat. #WAH266)……$5.95 each
8 ) Cell Phone Warning Signage.
CELL PHONES PROHIBITED SIGN
Indoor/Outdoor Cell Phone Warning Sign
Polyyethylene, outdoor grade sign telling people this is not a place to use cell phones. High density .055-gauge material that is resistant to breaking or weathering. This strong presence sign measures 10” x14”.
“HANG UP AND DRIVE” BUMPER STICKER
Help remind fellow motorists of one of the many dangers of cellphone use – driving while distracted! Good quality vinyl bumper sticker reads “Hang Up and Drive!”
NO CELL PHONE ZONE SIGN
Large No Cell Phone Sign
Made for indoor or outdoor use with sturdy corrugated plastic backing this large “No Cell Phone Zone” sign can be posted anywhere (work, school, home, etc) to discourage cell phone use. Sign measures12x18 inches.
NO CELLPHONES ALLOWED DECAL
Be clear when you want to establish a “No Cell Phones Zone”. This decal can be put up in offices, schools, hospitals, trains, homes or any other place you desire to limit exposure to microwave radiation. Decals measure 4″ by 4″. Very solid and strong adhesive, just peel and stick.
9) Books and Other Resources
BOOK: Public Health SOS: The Shadow Side of the Wireless Revolution
Read this primer on EMF and health by a leading EMF activist and world renowned EMF scientist to learn what the independent science shows about biological effects of electromagnetic fields, what you can do to create electromagnetically safe environments and how you can help get Congress to pay attention to this important issue affecting humans, animals and nature. Public Health SOS: The Shadow Side of the Wireless Revolution resulted from 110 Questions asked of the audience at The Commonwealth Club of California in 2008, the nations largest and oldest public affairs forum. 120 pages, 2009.
Electromagnetic Health: Making Sense of the Research and Practical Solutions for Electromagnetic Fields (EMF) and Radio Frequencies (RF)
By Case Adams
“Electromagnetic Health” examines the entire spectrum of electromagnetic radiation, from the swell of wireless technologies being used today to natural sources. The author presents evidence and the latest research from a perspective that embraces both the scientific and natural health communities. Note: this book is not affiliated with ElectromagneticHealth.org.
The Body Electric: Electromagnetism and the Foundation of Life
by Robert O. Becker & G. Selden
Another classic by Robert Becker, published in 1998. Becker was an inspiration to many scientists in bioelectromagnetics and is considered one of the fathers of the field. Anyone seriously interested in the healing potential of electromagnetic fields, and the risks of bathing ourselves in them with unchecked electropollution, should read Becker’s work.
Cell Towers: Wireless Convenience? or Environmental Hazard?
Ed. by B. Blake Levitt
Follow Blake Levitt on hazards from cell towers. She has an in depth knowledge of the cell tower science and will soon publish an updated review with Henry Lai, PhD.
Cross Currents: Promise of Electromagnetism, Perils of Electropollution
by Robert O. Becker
Published in 1990 this book is a classic. It reviews the promise of using electromagnetic fields for healing, without the side effects of toxic and invasive conventional modalities, and highlights the dangers of the growing electromagnetic pollution in our midst.
The Powerwatch Handbook: Simple Ways To Make You And Your Family Safer
by Alasdair and Jean Philips
The Powerwatch Handbook: Simple Ways to Make Your Environment Safer gives practical advice about electromagnetic fields and health, including education about outdoors and indoor sources, and special considerations for pregnancy, children and those who are electrically sensitive.
10) Grounding Devices.
Heavy duty static control mat (12” x 12” x 1/16”). Place on your desk so that your skin touches it when typing. Discharges static electricity. Includes a 5 ft grounding cord with alligator clip. Note this cord does not contain a safety resistor. For an Earthing™ grounding mat with 100,000 ohm resistor that plugs into your ground port in the electric outlet, and to learn about the new field of Earthing Science, please go to www.EarthingSecrets.com.
Anti-Static Mat (Cat. #WAH212) ………………….…. $39.95
Check Your Outlets for Improper Wiring and Faulty Ground
The Socket Tester checks your electric outlets for improper wiring and faulting ground. Electrical outlets can be improperly wired or damaged in a number of ways: a wire can short or fray, a wire can disconnect or corrode, or the wires can be connected to the wrong contact. Some outlets, especially older ones, don’t have any ground at all. These issues can potentially cause fire hazard or shock, are a problem for polarized appliances, and definitely a problem if you are using the outlet’s ground connection to ground your shielding materials, appliances or other grounding items like an Earthing sheet or pad.
Large LCD display lights up to indicate all the following possible issues:
– Voltage on ground connection
– Disconnected Ground
– Disconnected Neutral
– Disconnected Hot
– Interchanged Neutral and Hot
– Interchanged Ground and Hot
– Interchanged Ground and Hot, Neutral missing
– GFI function
Don’t ground to your electrical outlet without testing it first! North American plug only. Rated for 120V, 50/60 Hz.
11) Computer Accessories.
Ground Your Laptop
Most laptops are not grounded, even plugged in. Ungrounded electronics may emit high electric fields. Grounding helps to minimize this. The 6 foot ground cord plugs into the USB port and the other end plugs into a grounded wall outlet.
Use an outlet tester, like The Socket Tester above, to check your outlet for proper grounding before connection a laptop to ground.
USB ground cord (Cat. #WAH295-USB) …………… $8.95
Shielded Extension Cord
Shielded for Both Electric and Magnetic Fields
Compared to ordinary extension cords, these dramatically reduce field emission. North American style extension cords are made with 100% MuCord™ for superior electric and magnetic shielding. Use these with computer equipment, lighting, small appliances, power tools, etc. Can be used to move Stetzer (Dirty Electricity) filters further away from areas where people are. Link several together for a longer length cord. Run this extension cord anywhere you have power cords near your bed, workstation, couch or other main living area to reduce EMF to negligible amounts.
- Indoor use only
- NEMA 5-15 plug and socket (3-prong, grounded)
- Plug and socket color/style may vary
- Up to 14 Amp, 120V
6′ Long Extension Cord, Shielded (Cat. #WA738) …………… $33.40
12′ Long Extension Cord, Shielded (Cat. #WA739) …………… $42.90
This keyboard allows you to reduce your EMF exposure by increasing the distance between you and the computer. This is especially important with laptops, as their built-in keyboards are directly over the greatest source of EMF in the computer. The keyboard has 107 keys and connects to your computer’s USB port with a 54 inch long cable.
Remote Keyboard (Cat. #WAH248) ……. $9.95
Computer Mouse, ball type
Ultra low emission ball type mouse with retro design. Small supply available. Tests with a Trifield meter revealed no measurable magnetic or electric field emissions.
This mouse has two buttons, a 40 inch cable and PS2 plug. The old style ball for detection of movement means no high emission due to optical electronics. Will plug and play on most computers.
Computer Mouse (Cat. #WAH310) ………. $9.95
Protect your hands from radiation
You may be taking steps to protect your head and body from radiofrequency radiation and electromagnetic fields when you use a cellphone or computer, but your hands are often the closest to the source of radiation. To prevent ES symptoms in your hands when using electronic devices, these gloves form a conductive enclosure (with a resistivity of less than 10 Ohm/sq.), shielding radiowaves and electric fields, acting like a Faraday cage for your hands. They are soft and light weight and offer good tactile sensitivity. Made with polyester fiber twisted with pure Silver fibers, they are knit into a stretchy glove, which are hand washable and tested for 50 cycles with no appreciable loss of conductivity. They can also be used on touch screens like an iGlove.
12) Smart Meters
SMART METER SHIELD KIT
Everything You Need for Effective RF Shielding
This kit contains everything you’ll need to set up a simple but effective shield for a smart meter. The shielding kit covers an area of 8×7 feet and includes an RF reflector, an absorber material, mounting tape and a ground cord. The shielding is placed on the interior of the wall on which the meter is mounted and can be covered with any finish of your choice. When properly installed, it will shield almost all radiation emitted by the smart meter. Clear instructions are included.
It is important that the shield be placed between the source of radiation and the people you are protecting. It is also important to avoid sources of radiation (cordless phones, cellphones, wireless routers, wireless game systems, etc.) being placed on the interior side of the shield, as this will reflect RF back into the home.
For questions please email Info@ElectromagneticHealth.org.
LEARN MORE! Go to www.ElectromagneticHealth.org to hear free audio interviews of scientists talking about electromagnetic factors in health. You can purchase the E-Book: “Public Health SOS: The Shadow Side of the Wireless Revolution” there and hear the answers to 110 common questions on this topic asked by the audience at the Commonwealth Club of California.
Get up to speed now and create safe environments for you and your family!
